3-19
3. To connect the SMG-3200 and PBX or KTS with E&M line, connect one end of a RJ-11 cable
to the E&M port of the SMG-3200, and the other end to the E&M port of the PBX or KTS. At
this time, connect E line of one and M line of the other, and connect M line of one and E line of
the other.
E&M port of SMG-3200 E&M port of SMG-3200 E&M port of SMG-3200 E&M port of SMG-3200 E&M port of E&M port of E&M port of E&M port of PBX or KTS PBX or KTS PBX or KTS PBX or KTS
Pin Name Name Pin
1 M E 3
2 TxT RxT 1
3 RxT TxT 2
4 RxR TxR 27
5 TxR RxR 26
6 E M 28
4. To connect the SMG-3200 and PBX or KTS with E1/PRI, T1 line, connect one end of a RJ-11
cable to the E1/PRI, T1 port of the SMG-3200, and the other end to the E1/PRI, T1 port of the
PBX or KTS.
E1/PRI, T1 port of SMG-3200 E1/PRI, T1 port of SMG-3200 E1/PRI, T1 port of SMG-3200 E1/PRI, T1 port of SMG-3200 E1/PRI, T1 port of E1/PRI, T1 port of E1/PRI, T1 port of E1/PRI, T1 port of PBX or KTS PBX or KTS PBX or KTS PBX or KTS
Pin Name Name Pin
1 Tx+ Rx+ 2
2 Tx- Rx- 27
4 Rx+ Tx+ 1
5 Rx- Tx- 26
