Page 47
3-14
Chapter 3
Installing the System
RS-2
32C
LAN
MGC
B
E1/T
1/PR
I
PWR
L1
L2
LAN
TX LAN
RX
OPER
E1
SYNC E1
LOS
MGCB Board
On the MGCB board, the R2 board or E1/PRI, T1 board can be installed.
y To add 8 channel R2 signaling, install a R2 board.
☞ Install the R2 board.
y To connect to E1/PRI, T1 line
☞ Install an E1/PRI, T1 board.
Installing a daughter board on the MGCB board is relatively simple. Fit the daughter board into a
Slot of the MGCB board, and firmly secure it. Slots for a R2 board and E1/PRI, T1 board
installation are as follows.
