Front Panel and Structure of Board
There are E1/PRI, T1 ports, LAN port, RS-232C port, and system status LEDs on the MGCB
board. There are 8 DIP switches on the board.
❶ E1/PRI, T1 Port (RJ-45): for E1/PRI, T1 station line connection.
❷ LAN Port (RJ-45): for 10/100Mbps Ethernet LAN connection. It is connected to network
equipment such as a hub or switch.
❸ RS-232C Port: for system setup and testing using CLI (Command Line Interface). It is
usually connected to the serial port of a PC.
