Front Panel and Structure of Board
There are LEDs indicating VOIP board status on the front panel of the VOIP board.
VOIP Board With 8 Channels
❶ LED Indicators
LED
LED
LED
LED
Color
Color
Color
Color
Description
Description
Description
Description
8CH
LED is on when VOIP board is installed in system slot.
16CH
LED is on when the first daughter board is installed on VOIP board.
24CH
LED is on when the second daughter board is installed on VOIP
board.
32CH
Green
LED is on when the third daughter board is installed on VOIP board.
