6-4
Chapter 6
Web-based Remote Management
Configuration and Functions of Menu
The overview of each menu of the SMG-3200 web management interface is provided below. For
more detail, please refer to Chapter 5 CLI (Command Line Interface).
Menu Menu Menu Menu Functions Functions Functions Functions
Home Returns to the main screen of the SMG-3200 web management interface.
Network Configuration
Sets static IP address of the SMG-3200, subnet mask, default gateway
address and TOS (Type Of Service) values.
VoIP Configuration Sets general options for VoIP services.
VoIP Caller ID Table Sets the ID for VoIP call.
VoIP Routing Table Sets the Prefix to send and receive VoIP call through IP network.
VoIP Remote IP Table
For VoIP call service, at least one IP address need to be assigned in the
VoIP IP Table, which is set by VoIP Routing Table.
Gatekeeper
Configuration When the SMG-3200 is connected to Gatekeeper, it sets information for
Gatekeeper connection.
Voice Packetizer Sets voice control options for VoIP services.
PSTN Configuration
Sets general options for PSTN services such as operation mode and type
of PCM and dial.
PSTN Inbound LCR
Analyzes the dialing digits coming from PBX or KTS connected to
SMG-3200.
PSTN Call Control
Method
Sets the call control method to handle calls.
PSTN Gain Control Controls the call sensitivity according to the connection type.
PSTN Post Status Checks the system slots and the ports status.
MMC Port Block Decides whether to use a specific port.
Version Information Displays version information on the SMG-3200 system program.
Default DB Set Reset all items with the default values according to the database.
System Restart Restarts the SMG-3200 system.
LogOut Ends the connection of web management interface.
