5-53
3.
Set values for the selected item referring to the following table, and press
[Enter]. The settings of No.6,9,10 can be ‘Null’, when if necessary. In that
case, it sends the ‘Null’ to the connected Gatekeeper.
No
Item
Description
0
Gatekeeper
Connection
Sets whether Gatekeeper is to be connected.
Gatekeeper
Status
Displays the current status of connection to
Gatekeeper.
•
Unregistration : Indicates ‘no-connection’.
•
Registration : Indicates ‘connection’.
1
RAS Method
Selects manual to connect to the Gatekeeper or not
according to the Prefix, and selects Auto for the rest of
the case.
2
Registration
Type
Sets the registration type for Gateway when it
registered to Gatekeeper. The types include E.164 ID
of Gateway mode and Caller ID in the Caller ID Table.
3
Gatekeeper
Type
Specifies the manufacturer of Gatekeeper.
SIGK : Select if Samsung Internet Gatekeeper is to be
connected..
Other GK : Select if other company’s Gatekeeper is to
be connected.
4
GW Routing In
GK mode
This feature is used when SMG-3200 analyzes the
dialing digits when it is connected to Gatekeeper.
Generally Gatekeeper analyzes the digits, but with this
feature, SMG-3200 analyzes the dialing digits using
the data in VoIP Outbound Routing Table of [3] VoIP
Routing Table.
5
Gatekeeper IP
Sets IP address of the Gatekeeper to be connected.
6
Gatekeeper
Alias
Sets H.323 Alias Name of the Gatekeeper to be
connected.
7
Alternative
Gatekeeper IP
When Gatekeeper is to be duplicated, and the
connection to the primary Gatekeeper is disconnected,
it sets the other Gatekeeper’s IP address.
