Front panel and structure of board – Samsung SMG-3200 User Manual
Page 31
2-13
The features and functions of the E&M board are as follows.
y Transformer and impedance matching circuits are built in.
y It encodes the entered analog signal into the digital signal of the PCM method where the digital
signal is decoded into the analog signal on the system through the PCM method.
y There is separate logic to the control port of the board.
y It has an outgoing signal control logic and incoming signal Detection logic.
Front Panel and Structure of Board
E&M Board with 8 ports
