5-38
Chapter 5
CLI (Command Line Interface)
[11] Diagnosis
Function You can set a regular interval to diagnose the PSTN interface of the SMG-3200.
Setting it to ‘0’ it bypasses the diagnosis. You can set the interval at units of 1sec
by the test type.
Procedure 1. In the screen, type ‘11’, and press [Enter].
2. Input the number of the diagnosis interval to be changed, and press [Enter].
Configuration Item Number:
3. Set the diagnosis interval referring to the following table, and press [Enter].
Typed number x 1sec is the actual time.
No No No No Item Item Item Item Description Description Description Description
0 SLI Port Test Sets the diagnosis interval for SLI port test.
1 Trunk Seizure Test
It sets the diagnosis interval for trunk seizure
test.
2 Trunk CODEC Test
It sets the diagnosis interval for trunk CODEC
test.
SLI refers to SLC, Trunk refers to LOOP and E&M.
When you test the E&M port, you should connect the E&M JIG.
