3-7
Rack Requirements
Before installation of SMG-3200 system in a rack, you have to prepare a rack that meets the
following requirements.
y Prepare a rack with standard electrical facilities.
y Ensure that the rack has appropriate ventilators, if it is closed type. A closed type rack should
provide at least one ventilator with fan on the side of the rack in order to circulate cool air into
the rack.
y Pay attention in a closed type rack as the ventilator may cause hot air from the lower system to
rise up to the port opening of a system installed in an upper position in the rack.
y Ensure not to block up the port or fan of installed systems, if the rack is opened type.
y Ensure that the rack is equipped with an internal power bar, and is located near power supply
units.
y Ensure that the rack has ventilators on the side as well as backside for smooth air circulation.
Required Tools
y Cross-shaped medium-size screwdriver
y L-shaped Bracket
y Screws
