Icom IC-2800H - Manual (Page 71)

67
15
OTHER FUNCTIONS
■ Memory name indication
The transceiver can display
memory names programmed
in memory or call channels. (p.
32)
q Push [ (DISP) SET] for 2 sec. to enter set mode.
• Push [CHG/L] if [(DISP) SET] is not displayed.
w Push [ Y ] or [ Z ] to select the ‘Memory Name’ item.
• Left-hand tuning dial can also
select the item.
e Rotate the right-hand tuning
dial to turn the memory
name indication ON or OFF.
r Push [ ï ] to exit set mode.
q Push [ F SET] to enter set mode.
w Push [ F SET] or [ G ENT] to select the ‘Memory
Name’ item.
e Push [ Y ] or [ Z ] to turn the memory name indi-
cation ON or OFF.
r Push [ E CLR] to exit set mode.
■ HM-98 [F-1]/[F-2] keys
Switches on the transceiver’s front panel can be assigned to
the HM-98 [F-1] and [F-2] keys. The following can be as-
signed:
V/U MAIN : [MAIN (SCP)] V/U V/MHz : [V/M H (TS)]
V/U M/C : [M/C (SCN)] V/U MONI : [MONI (LOW)]
V/U EDIT : [MAIN (EDIT)] V/U TONE : [TON (DUP)]
V/U MW : [S.MW (MW)] DTMF : [DTMF]
DISP : [DISP (SET)] Up : Microphone’s up
Dn : Microphone’s down
q Push [ (DISP) SET] for 2 sec. to enter set mode.
• Push [CHG/L] if [(DISP) SET] is not displayed.
w Push [ Y ] or [ Z ] to select the ‘HM-98 F-1’ or ‘F-2’ item.
• Left-hand tuning dial can also
select the item.
e Rotate the right-hand tuning
dial to select the desired
function.
r Push [ ï ] to exit set mode.
q Push [ F SET] to enter set mode.
w Push [ F SET] or [ G ENT] to select the ‘HM-98
F-1’ or ‘F-2’ item.
e Push [ Y ] or [ Z ] to select the desired function.
r Push [ E CLR] to exit set mode.
ï Y
Z
SET
Sub Band Beep
OFF
OFF
OFF
VHF M/C
UHF M/C
RF Attenuator
Memory Name
HM-98 F-1
HM-98 F-2
ï Y
Z
SET
Memory Name
OFF
VHF M/C
UHF M/C
Up
Dn
HM-98 F-1
HM-98 F-2
HM-118 Up
HM-118 Dn
12
EDIT
MAIN
DUP
TON
M I D - L O
DISP
SET
MW
S.MW
EDIT
MW
S.MW
EDIT
MAIN
DUP
TON
ICOM2800
14 5.320
MAIN
M I D - L O 12
43 3.000
JA3YUA
SET
B
SET
B
