■ Transmitting a DTMF code
D Automatic transmission (DTMF memory)
The selected DTMF code is transmitted at each push of the
PTT switch when the DTMF memory encoder is turned ON.
q Push [DTMF] to turn the DTMF memory encoder ON.
• Push [CHG/L] if [DTMF] is not displayed.
• “
” appears.
w Push [DTMF] for 2 sec. to select the DTMF memory
screen.
e Push [ Y ] or [ Z ] to select the desired DTMF memory.
• Left-hand tuning dial can also select the item.
r Push [ ï ] to exit the DTMF memory screen.
t Push [PTT] to transmit the selected DTMF code.
• Each push of [PTT] transmits the DTMF code.
• The speaker emits the DTMF tones sent.
y Push [DTMF] to cancel the DTMF memory encoder.
• “ ” disappears.
q Push [FUNC] then [ y DTMF] to turn the DTMF
memory encoder ON.
• “ ” appears.
w Set the desired DTMF memory in the DTMF
memory screen using the remote controller
unit.
• Follow steps w through r above.
• See the previous page for programming.
e Push [PTT] to transmit the selected DTMF code.
• Each push of [PTT] transmits the DTMF code.
r Push [ E CLR] to cancel the function.
D Transmitting a DTMF memory directly
q Push [FUNC] then [ y DTMF] to turn the DTMF
memory encoder ON.
• “ ” appears.
w Push [DTMF-S] to activate the DTMF setting.
• Function indicator on the HM-98 lights green.
e Push the desired DTMF channel number.
• “0” to “9” and “A” to “D” are available for channel
numbers.
r Push [DTMF-S] again to deactivate the DTMF
setting.
• Function indicator on the HM-98 disappears.
t Push [ E CLR] to turn the DTMF memory en-
coder OFF.
• When the DTMF memory encoder is turned ON
continuously, each push of the PTT transmits the
previously selected DTMF code.
