Icom IC-2800H - Manual (Page 37)

33
7
MEMORY/CALL CHANNELS
■ Programming after selection
q Select memory mode with the desired band’s [M/C].
• Push [CHG/L] if [M/C] is not displayed.
• “
! ” appears when memory mode is selected.
w Set the memory channel to be programmed with the de-
sired band’s tuning dial.
e Push [V/M H ] to select VFO mode.
r Set the desired frequency:
➥ Set the frequency using the desired band’s tuning dial.
➥ Set other data (e.g. offset frequency, duplex direction,
subaudible tone frequency, etc.), if required.
t Push [ (S.MW) MW] for 2 sec. to program into the selected
channel.
• Push [CHG/L] if [(S.MW) MW] is not displayed.
• Memory channel number automatically advances when continu-
ing to push [MW] after programming.
■ Transferring memory
contents to another memory
q Select memory mode with the desired band’s [M/C].
• Push [CHG/L] if [M/C] is not displayed.
• “
! ” appears when memory mode is selected.
w Set the desired memory channel with the desired band’s
tuning dial.
e Push the desired band’s [S.MW] momentarily to indicate
memory channels.
• Push [CHG/L] if [S.MW] is not displayed.
• Push [S.MW] for 2 sec. to transfer the memory channel contents
to VFO.
r Rotate the tuning dial to select the desired channel.
• Call channel (C), VFO (- -) and scan edges (1A – 3B), as well as
regular memory channels, can be transferred in this way.
t Push [ (S.MW) MW] for 2 sec. to transfer.
MAIN
3
14
6.340
M I D - L O
MAIN
20
14
6.340
M I D - L O
MAIN
EDIT
TON
DUP
MAIN
- -
14
6.010
M I D - L O M
MAIN
EDIT
TON
DUP
MAIN
20
5 .
M I D - L O M M
MAIN
EDIT
TON
DUP
S.MW
MW S.MW
MW
SCP
MAIN
TS
V/M H
SCN
M/C
SCP
MAIN
TS
V/M H M
Select memory
channel
momentarily
blank channel
for 2 sec.
CHG/L
[EXAMPLE]: Transferring VHF memory channel 3 to 20.
