Chapter 15 – GPRS Commands
Multi-Tech Systems, Inc. Wireless GSM/GPRS AT Commands (Document Number S000293I) 152
Reliability
Class GTP Mode LLC Frame Mode LLC Data
Protection
RLC Block Mode Traffic Type
0 Subscribed Subscribed by the Nwk / default if value is omitted
1 Acknowledged Acknowledged Protected Acknowledged Non real-time traffic, error-sensitive
application that cannot cope with
data loss.
2 Unacknowledged Acknowledged Protected Acknowledged Non real-time traffic, error-sensitive
application that can cope with
infrequent data loss.
3 Unacknowledged Unacknowledged Protected Acknowledged Non real-time traffic, error-sensitive
application that can cope with data
loss, GMM/SM, & SMS.
4 Unacknowledged Unacknowledged Protected Unacknowledged Real-time traffic, error-sensitive
application that can cope with data
loss.
5 Unacknowledged Unacknowledged Unprotecte
d
Unacknowledged Real-time traffic, error non-sensitive
application that can cope with data
loss.
Note: For real-time traffic, the QoS profile also requires appropriate settings for delay and throughput.
0 Subscribed
1 Up to 1 000 (8 kbit/s)
2 Up to 2 000 (16 kbit/s)
3 Up to 4 000 (32kbit/s)
4 Up to 8 000 (64 kbit/s)
5 Up to 16 000 (188 kbit/s)
6 Up to 32 000 (256 kbit/s)
7 Up to 64 000 (512 kbit/s)
8 Up to 128 000 (1 024 kbit/s)
9 Up to 256 000 (2 048 kbit/s)
0 Subscribed by the Network by default if value is omitted
1 100 (~0.22 bit/s)
2 200 (~0.44 bit/s)
3 500 (~1.11 bit/s)
4 1 000 (~2.2 bit/s)
5 2 000 (~4.4 bit/s)
6 5 000 (~11.1 bit/s)
7 10 000 (~22 bit/s)
8 20 000 (~44 bit/s)
9 50 000 (~111 bit/s)
10 100 000 (~0.22 kbit/s)
11 200 000 (~0.44 kbit/s)
12 500 000 (~1.11 kbit/s)
13 1 000 000 (~2.2 kbit/s)
14 2 000 000 (~4.4 kbit/s)
15 5 000 000 (~11.1 kbit/s)
16 10 000 000 (~22 kbit/s)
17 20 000 000 (~44 kbit/s)
18 50 000 000 (~111 kbit/s)
31 Best effort
