Chapter 13 – Specific AT Commands

Multi-Tech Systems, Inc. Wireless GSM/GPRS AT Commands (Document Number S000293I)

115

Input/Output Management +WIOM

Description:

This command sets the default GPIO’s configuration (input or output) after reset, and each GPIO default
value (if set as an output) after reset.

Notes:

This command is allowed only on a GPIO not allocated by the Open-AT embedded application or
for bus operations.

When UART is activated, GPIOs 0 and 5, GPO2 and GPI are not available anymore. When you
try to do writable or readable operations on these I/O, CME ERROR: 3 will be returned. This
applies for modems running AT X50 software and supporting the multi-UART feature.

When the BT chip is switched on, the GPIO5 is not available anymore. It is not possible to

change the state of the GPIO using this command.

Values:

Bit table parameter indicating each GPIO direction.

0 Input
1

Output. Default.

Default value: 2047 (all GPIOs set as outputs).

Bit table parameter indicating each output-configured GPIO value (each bit gives the

corresponding GPIO default value).
0

Reset. Default.

1 Set
The GPIOs set as inputs by the parameter are not affected by the value set by the
parameter.

Notes:

bit values for GPI and GPO are ignored.

bit values for GPI are ignored.

Syntax: Command

syntax:

AT+WIOM=[],[]

Command

Possible responses

AT+WIOM? +WIOM:

2047,0

OK
On reset, all GPIOs are set to 0, as an output

AT+WIOM=? +WIOM:

(0-2047),(0-2047)

OK
Range allowed for the parameters.

AT+WIOM=254
Set GPIO 0 as an input, and all others as outputs

OK

AT+WIOM=,128
Set GPIO 3; default output value to 1

OK

AT+WIOM=,128
Note: Set GPIO 8 or GPIO12 or GPIO7; default
output value to 1

OK
