Programming Model
http://www.motorola.com/computer/literature 1-23
1
The following table shows the programmed values for the associated
Universe registers for the VMEbus slave function.
Table 1-13. Universe PCI Register Values for VMEbus Slave Map Example
Configuration
Address Offset
Configuration
Register Name
Register Value
(CHRP)
Register Value
(PREP)
$F00 VSI0_CTL C0F2 0001 C0F2 0001
$F04 VSI0_BS 4000 0000 4000 0000
$F08 VSI0_BD 4000 1000 4000 1000
$F0C VSI0_TO C000 1000 C000 1000
$F14 VSI1_CTL E0F2 00C0 E0F2 00C0
$F18 VSI1_BS 1000 0000 1000 0000
$F1C VSI1_BD 2000 0000 2000 0000
$F20 VSI1_TO F000 0000 7000 0000
$F28 VSI2_CTL 0000 0000 0000 0000
$F2C VSI2_BS XXXX XXXX XXXX XXXX
$F30 VSI2_BD XXXX XXXX XXXX XXXX
$F34 VSI2_TO XXXX XXXX XXXX XXXX
$F3C VSI3_CTL 0000 0000 0000 0000
$F40 VSI3_BS XXXX XXXX XXXX XXXX
$F44 VSI3_BD XXXX XXXX XXXX XXXX
$F48 VSI3_TO XXXX XXXX XXXX XXXX
