Raven PCI Bridge ASIC

Vendor ID/Device ID Registers

VENID

Vendor ID. Identifies the manufacturer of the device. The
identifier is allocated by the PCI SIG to ensure
uniqueness. $1057 has been assigned to Motorola. This
register is duplicated in the PCI Configuration registers.

DEVID

Device ID. Identifies this particular device. The Raven
will always return $4801. This register is duplicated in the
PCI Configuration registers.

$FEFF0060

$FEFF0064

$FFEF0068

$FEFF006C

$FEFF0070

GPREG0(Upper)

$FEFF0074

GPREG0(Lower)

$FEFF078

GPREG1(Upper)

$FEFF07C

GPREG1(Lower)
