Raven Interrupt Controller

http://www.motorola.com/computer/literature

2-73

Feature Reporting Register

NIRQ

NUMBER OF IRQs. The number of the highest external
IRQ source supported. The IPI, Timer, and Raven
Detected Error interrupts are excluded from this count.

NCPU

NUMBER OF CPUs. The number of the highest physical
CPU supported. This design supports two CPUs (CPU 0
and CPU 1).

VID

VERSION ID. Version ID for this interrupt controller.
This value reports what level of the specification is
supported by this implementation. A version level of 02 is
used for the initial release of the MPIC specification.

Offset

$01000

Bit

3
1

3
0

2
9

2
8

2
7

2
6

2
5

2
4

2
3

2
2

2
1

2
0

1
9

1
8

1
7

1
6

1
5

1
4

1
3

1
2

1
1

1
0 9 8 7 6 5 4 3 2 1 0

Name

FEATURE REPORTING

NIRQ

NCPU

VID

Operation

Reset

$00F

$01

$02
