Raven Registers

http://www.motorola.com/computer/literature

2-49

2

Table 2-9. Raven PCI I/O Register Map

Vendor ID/ Device ID Registers

VENID

Vendor ID. Identifies the manufacturer of the device.
This identifier is allocated by the PCI SIG to ensure
uniqueness. $1057 has been assigned to Motorola. This
register is duplicated in the MPC registers.

DEVID

Device ID. Identifies the particular device. The Raven
will always return $4801. This register is duplicated in the
MPC registers.

3
1

3
0

2
9

2
8

2
7

2
6

2
5

2
4

2
3

2
2

2
1

2
0

1
9

1
8

1
7

1
6

1
5

1
4

1
3

1
2

1
1

1
0 9 8 7 6 5 4 3 2 1 0

<--- Bit

CONFIG_ADDRESS

$CF8

CONFIG_DATA

$CFC

Offset

$00

Bit

3
1

3
0

2
9

2
8

2
7

2
6

2
5

2
4

2
3

2
2

2
1

2
0

1
9

1
8

1
7

1
6

1
5

1
4

1
3

1
2

1
1

1
0 9 8 7 6 5 4 3 2 1 0

Name

DEVID

VENID

Operation

R

R

Reset

$4801

$1057
