8 - 35 8 - 35
MELSEC-Q
8 UTILITY PACKAGE (GX Configurator-SC)
Monitor/test items
Setting value storage
buffer memory address
Reference section containing
detailed explanation
Y11: Connection request —
Y12: Modem disconnection request —
Y14: Notification-issued request —
Modem connection channel designation 2E
H
Notification execution designation 2F H
Number of connection retires designation 30 H
Connection retry interval designation units: s 31
H
Initialization/connection timeout designation units: s 32 H
Number of initialization retries designation 33 H
Data No. for initialization designation 34
H
Data No. for connection designation 35 H
GX Developer connection designation 36 H
No-communication interval time designation units: min 37 H
RS · CS control yes/no designation 38 H
Modem initialization time DR signal valid/invalid designation 2008
H
Wait time of notification units: s 200A H
Circuit disconnect wait time (PLC CPU watch use) units: s 200E H
Remote password mismatch notification count designation 200C
H
Remote password mismatch notification accumulated count
designation
200D
H
Accumulated count of unlock process normal completion 22FB
H
Accumulated count of unlock process abnormal completion 22FC H
Accumulated count of lock process based on circuit disconnection 22FF
H
Auto modem initialization designation 2007 H
Callback function designation 2001 H
Callback denial notification accumulated count designation 2002
H
Data No. for Callback designation 1 to 10 2101 H to 210A H
Callback permit accumulated count 22F0 H
Callback denial accumulated count 22F1
H
Auto (callback) connection permit accumulated count 22F2 H
Auto (callback) connection denial accumulated count 22F3 H
Accumulated count of callback receive procedure cancel 22F4
H
Section 3.3 of
User's Manual (Application)
