42
Installing internal options to 5-inch expansion bays
○ ○ ○ ○ ○ ○ ○ ○
This section explains how to install 5-inch expansion bay options such as CD-ROM drive and
5-inch floppy disk drive. A CD-ROM drive is used below in an example of installation. Up to two
5-inch expansion bay options can be installed in your PC.
Point
The retaining metal bracket is required for installing a 3.5-inch hard disk or magneto-optic disk
drive.
1
Configure the internal option.
See the manual accompanying the internal options to configure the following items.
- To install an IDE-standard internal option:
Set the master, slave, and cable select.
- To install a SCSI interface internal option:
Configure the SCSI ID.
2
Remove the upper cover.
3
Remove the front panel.
4
Remove the blank panel (for installing the
internal option to the lower 5-inch
expansion bay).
Remove a screw to remove the blank panel.
5
Insert the internal option from the front
side of the PC main unit
Retaining
metal bracket
