95
Appendix
Ventilation holes
The heat within the PC main unit is
ventilated through these holes. Keep
them free.
USB connector
Connect the peripherals conforming to the USB standard.
Security lock
You can connect a security-use cable bought
on the market.
LAN connector ( : NETWORK)
Connect the LAN cable.
CRT connector
( : MONITOR)
Connect the CRT cable.
2
1
Parallel connector
( : PRINTER)
Connect the printer cable. It is also
called a parallel port.
Keyboard connector ( : KEYBOARD)
Connect the keyboard cable.
Mouse connector ( : MOUSE)
The heat within the PC main unit is ventilated
through these holes. Keep them free.
DVI
Connect Digital Video Interface
Serial connector
( : SERIAL PORT1)
( : SERIAL PORT2)
Connect a RS-232C interface device such as a modem.
