CHAPTER 3 CPU

●

Go to normal state (RUN) and reset

●

Go to/wake-up from standby mode

Table 3.7-3 Go to main clock mode run state and reset

State transition

Conditions/events required for transition

Products with power-on reset

(Figure 3.7-2 )

Products without power-on reset

(Figure 3.7-3 )

Go to normal state
(RUN) after power-on

[1] Main clock oscillation stabilization delay

time completes (timebase timer output).

[2] Wake-up from Reset input.

[1] External reset input must be held asserted

until main clock oscillation has had time to
stabilize.

[2] Wake-up from reset input de-asserted.

Reset in RUN state

[3] Have external, software, or watchdog reset.

Table 3.7-4 Go to/wake-up from standby mode

State transition

Conditions/events required for transition

Products with power-on reset

(Figure 3.7-2 )

Products without power-on reset

(Figure 3.7-3 )

Go to sleep mode

[1] STBC: SLP = "1"

Wake-up from sleep
mode

[2] Interrupt
[3] External reset

Go to stop mode

[4] STBC: STP = "1"

Wake-up from stop
mode

[5] External interrupt
[6] Main clock oscillation stabilization delay
time completes (timebase timer output).
[7] External reset
[8] External reset (during oscillation
stabilization delay time)

STBC: Standby control register
