52
CHAPTER 3 CPU
●
External clock
Connect the external clock to the X0 pin and leave X1 pin open, as shown in Figure 3.6-3 "Connection
example for external clock".
Figure 3.6-3 Connection example for external clock
X0 X1
Main clock
oscillator
MB89950/950A series
Open
