104
CHAPTER 5 TIMEBASE TIMER
5.3 Timebase Timer Control Register (TBTC)
The timebase timer control register (TBTC) is used to select the interval times bit, clear
the counter, control interrupts, and check the state of the timebase timer.
■ Timebase timer control register (TBTC)
Figure 5.3-1 Timebase timer control register (TBTC)
Address Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Initial value
000A H
TBIF TBIE TBR TBC1 TBC0 ---00000
B
R/W R/W W R/W R/W
TBC1 TBC0 Interval time selection bits
0 0 2 15 /F CH
0 1 2 17 /F CH
1 0 2 19 /F CH
1 1 2 21 /F CH
TBR
Timebase timer initialization bit
Read Write
0 —
Clears timebase timer
counter
1
Reading always returns
"1".
No effect. The bit does
not change.
TBIE Interrupt request enable bit
0 Disables interrupt request output.
1 Enables interrupt output.
TBIF
Overflow interrupt request flag bit
Read Write
0
No overflow on specified
bit.
Clears this bit.
1 Overflow on specified bit.
No effect. The bit does
not change.
R/W :Readable and writable
W :Write-only
— : Unused
: Initial value
F CH : Main clock oscillation frequency
