OPERATOR’S MANUAL
10" Virtual Terminal
11001-1440-200701
VT INSTALLATION / 5
NOTE: The ignition lead must be
connected to a switched
+12VDC for the system to
power properly.
VT CAB HARNESS CONNECTIONS
1. Connect the power leads directly to the battery.
2. Connect the ignition wire to a switched +12VDC.
3. Connect the Chassis Ground lead to a bare point of the cab frame that
offers a good chassis ground connection.
4. Connect the Master Switch, CAN Terminator, Radar Speed Sensor,
and Tractor ECU to their respective connectors on the cab harness. If
the speed sensor is on the tractor, connect to the cab harness. If the
sensor is on the implement, connect to the IntelliAg.
Refer to the IntelliAg PDC Operator’s manual for implement harnessing
connections.
