OPERATOR’S MANUAL
10" Virtual Terminal
11001-1440-200701
12 / VT DISPLAY
VT SETUP/CONFIGURATION MODE
Virtual Terminal (VT) setup enables customization of the basic operating
parameters to the operator’s preferences and configuration of applications
enabled with the system.
VT configuration parameters include:
• Information
• Regional and Unit Setting
• Display/Volume Setup
• Auxiliary Input Assignment
• Date and Time Setup
• Application Selection
To Enter Virtual Terminal Setup Mode:
1. Make sure the Master Switch is in the OFF position (SETUP/
CONFIGURATION mode).
2. Press the Virtual Terminal button.
The VT Setup/Configuration screen will appear as shown in (
Figure 9
) and
is the main screen that all other VT setup screens can be accessed.
Figure 9
10” VT Setup Screen
INFORMATION
The Information screen provides software version details and contact
information for troubleshooting assistance, refer to (
Figure 9
).
REGIONAL AND UNIT SETTINGS
The Regional and Units setup screen allows customization of the display
based on user preference. The values are edited by touching the left and
right arrows on the display.
Virtual Terminal button
Information button
Regional and Unit Settings button
