Viewing the Front Panel 85
FS6300 NMS User Manual 6 • Configuring the 3096RC Card
• Ethernet Overview – See “Configuring Ethernet Settings” on page 87
• Events and Alerts – See “Viewing Events and Alerts” on page 62
• G.SHDSL Port Configuration – See “Configuring G.SHDSL Ports” on page 88
• G.SHDSL Report – See “Viewing G.SHDSL Reports” on page 92
• IP Routing – See “Configuring IP Routing” on page 93
• Operator Action – See “Managing Operator Actions” on page 60
• PPP Configuration – See “Configuring PPP” on page 95
• System Log – See “Viewing/Modifying System Log Configuration” on page 65
• T1E1 Port Configuration – See “Configuring the T1/E1 Ports” on page 99
• T1E1 Reports – See “Viewing T1/E1 Reports” on page 103
• Re-Discover Card – See “Re-Discovering Cards Manually” on page 38
• Ping – Displays a status message after pinging the interface.
Viewing the Front Panel
Click on Card Front Panel GUI to view the front panel of the card in real-time.
Figure 72. 3096RC Front Panel LEDs
Configuring the Card System
Click on Card System Configuration to configure system parameters. You can also view the system status, eth-
ernet status, system parameters, SNMP and HTTP Parameters, and system status details.
Modify System Parameters
If you only want to view the system parameters, click on View System Parameters in the Card System Config-
uration window.
To configure the card system, click on Modify System Parameters in the menu tree in the Card System Con-
figuration window (see
Figure 71 on page 84).
