Viewing T1/E1 Reports
124
FS6300 NMS User Manual
7 • Configuring the 3196RC Card
Viewing T1/E1 Reports
Click on T1E1 Reports to view and print different reports about the activity, line interface settings, and test
settings of T1/E1 links on the 3196RC card.
Click the Print button to send the report to a printer on your network.
Click the Export to Excel button to send the report to Microsoft Excel to save in a spreadsheet.
Figure 107. 3196RC T1/E1 Reports
Viewing the T1/E1 Map Layer
Click on Display T1E1 Map Layer to show a map of all the T1/E1 ports on the card. Right-click on a port in
the map to configure its link. See
on page 120 for more details.
Figure 108. 3196RC T1/E1 Port Map
