Page 107: 3196rc front panel leds

Viewing the Front Panel
107
FS6300 NMS User Manual
7 • Configuring the 3196RC Card
•
Ethernet Overview – See
“Configuring Ethernet Settings”
•
Events and Alerts – See
•
iDSL Port Configuration – See
•
•
•
•
PPP Configuration – See
•
“Viewing/Modifying System Log Configuration”
•
T1E1 Port Configuration – See
•
T1E1 Reports – See
•
Re-Discover Card – See
“Re-Discovering Cards Manually”
•
Ping – Displays a status message after pinging the interface.
Viewing the Front Panel
Click on Card Front Panel GUI to view the front panel of the card in real-time.
Figure 92. 3196RC Front Panel LEDs
Configuring the Card System
Click on Card System Configuration to configure system parameters. You can also view the system status, eth-
ernet status, system parameters, SNMP and HTTP Parameters, and system status details.
Modify System Parameters
If you only want to view the system parameters, click on View System Parameters in the Card System Config-
uration window.
To configure the card system, click on Modify System Parameters in the menu tree in the Card System Con-
figuration window (see
