Configuring PPP 74
FS6300 NMS User Manual 5 • Configuring the 2616RC Card
Configuring PPP
Click on PPP Configuration to view PPP links for the card. You may also modify the link configuration and
default packet settings for PPP links.
Modify PPP Link Configuration
To configure PPP links for the card:
1. Right-click on the card in the main window and select PPP Configuration. The PPP2616 window dis-
plays.
2. Click on PPP View and select an entry to edit from the table. The FS6300-PPP window displays.
3. Select Modify Link Configuration..
Figure 64. PPP Link Configuration
4. Edit the desired options:
– PPP Protocol: The desired kind of PPP protocol.
• ppp-ipcp(1) —point-to-point protocol
• ppp-bcp(2)—bridge control protocol
– Authentication Technique: The login technique to use for authentication.
• none(0)—No authentication will be used
• pap(3)—password authentication protocol will be used
• chap(4)—challenge handshake authentication protocol will be used
• chapORpap(5)—chap will be negotiated first, if that fails, pap will be attempted
