Starting the Discovery Process 32
FS6300 NMS User Manual 2 • Discovering Your Network
Starting the Discovery Process
Before starting the Discovery process, at least one node must be deployed, powered up, and connected to the
network.
Enabling AutoDiscovery
To start Discovery:
1. From the Tools menu at the top of the screen, select Discovery Administration.
The Discovery Window displays.
2. Click on Discover Patton Devices in the tree on the left side of the screen.
3. Click on the Auto-Discovery checkbox.
Figure 15. Discovery Window
