Page 98
98
A
PPENDIX
D
D
ECODE
Z
ONE
The decode zones for the Socket Bluetooth Cordless Hand Scanner are shown below.
The minimum element width (“X Dimension” or barcode “size”) is the width in
thousandths of an inch (mils) of the narrowest element (bar or space) in the symbol.
The figures shown are the typical scanning distances (depths of field) for selected
barcode sizes. The maximum usable length of a barcode symbol (Width of Field) at
any given range is also shown.
Bluetooth CHS 7E2/7NRx
