APPENDIX F: CHANGING THE DATA MODE
101
A
PPENDIX
F
C
HANGING THE
D
ATA
M
ODE
Check the table below to determine the default data mode of your Bluetooth CHS.
The part number is printed on a barcode inside the battery door. By default, the
latest versions of the Bluetooth CHS send data in packet mode in order to support
Error Proof Protocol.
Bluetooth CHS version
Part Number
Default Data Mode
7E2 gray
8550-00050
8550-00051
packet
7E2 yellow
8550-00052
packet
7M 8550-00038
packet
7M yellow
8550-00041
packet
7P 8550-00039
packet
7NRx 8550-00046
packet
7M 8550-00005
8550-00008
8550-00014
raw
7P 8550-00006
8550-00009
8550-00015
raw
7X
7XRx
Note: In raw data format, the ACK/NAK handshaking is disabled for decode data.
There are three ways to configure the data mode of the Bluetooth CHS:
• Binary data: Compatible with all versions of the Bluetooth CHS. Programmers
can change the data mode of the Bluetooth CHS by sending the following
binary data to it:
Send Raw Decode Data:
0x07 0xC6 0x04 0x00 0xFF 0xEE 0x00 0xFD 0x42
Send Packeted Decode Data:
0x07 0xC6 0x04 0x00 0xFF 0xEE 0x01 0xFD 0x41
• Scan Params configuration utility: Compatible with all versions of the Bluetooth
CHS, available for Windows Mobile or Palm OS. Download the utility from:
