Installing the Hardware
3-2 HP Smart Array 5300 Controller User Guide
HP CONFIDENTIAL
Writer: Jennifer Hayward File Name: d-ch3 installing the hardware
Codename: SilverHammer Part Number: 135606-005 Last Saved On: 10/8/02 11:11 AM
4. Unplug the AC power cord from the outlet, and then from the server.
IMPORTANT: If you will be replacing a Smart controller with a Smart Array controller, see
the “External Cabling for HP Servers” section to determine the external cabling
requirements.
5. Disconnect any peripheral devices from the server.
WARNING: To reduce the risk of personal injury from hot surfaces, allow
the internal system components and hot-plug hard drives to cool before
touching them.
CAUTION: Electrostatic discharge (ESD) can damage electronic components.
Be sure that you are properly grounded before continuing the installation
procedure. See Appendix B for ESD information.
Installing the Smart Array Controller
1. Remove or open the access panel.
2. Select an available 66-MHz PCI slot. Slots that use a 64-bit interface may
provide higher performance.
3. Remove the slot cover or open the hot-plug latch. Save the retaining screw, if one
is present.
4. Slide the controller board along the slot alignment guide.
