HP Smart Array 5300 Controller User Guide C-1
HP CONFIDENTIAL
Writer: Jennifer Hayward File Name: m-appc specifications
Codename: SilverHammer Part Number: 135606-005 Last Saved On: 10/8/02 11:20 AM
C
Controller Specifications
Table C-1: Controller Specifications
Dimensions 31.5 cm × 10.8 cm × 1.5 cm (12.4 in × 4.3 in × 0.6 in)
Power required 21.2 W for 5302 (16.3 W at 3.3 V, 4.8 W at 5 V)
24.9 W for 5304 (19.0 W at 3.3 V, 5.9 W at 5 V)
PCI Bus transfer rate Up to 528 MB/s
SCSI Bus
Number of channels 4 (5304), or 2 upgradeable to 4 (5302)
Number of drives per channel Up to 14
Connector type 68-pin Wide internal, VHDCI external
Termination Required, but provided on HP and Compaq branded
systems
Transfer rate Up to 160 MB/s (40 MHz) per channel
Temperature Range
Operating 10 ° to 35°C (50° to 95°F)
Shipping -30 ° to 60°C (-22° to 140°F)
Relative Humidity (Non-condensing)
Operating 20% to 80%
Non-operating 5% to 90%
