4-16
Using the Universal Volume Manager GUI
Hitachi Universal Storage Platform V/VM Universal Volume Manager User’s Guide
–
Margin: The additional wait time (in seconds) to FLI_TOV (FLOGI wait
time) or PLI_TOV (PLOGI wait time). This value is automatically set by
Universal Volume Manager. You cannot change the value. As a result,
the sum of FLI_TOV time and the margin time, or the sum of
PLI_TOV time and the margin time is set as a total wait time.
–
Status: Status of the cross-subsystem path. Table 4-7 shows the
displayed statuses.
•
Pop-up menu
Right-click a row in the Path Operation list to perform the operations from
Table 4-7
Status of the Cross-subsystem Path Displayed in the Status
Displayed
Item
Description
Normal
The cross-subsystem path is normal.
-
The status of the cross-subsystem path is not retrieved yet. Click Status: Disable in
the Path Operation window to display the status of the cross-subsystem path.
Unknown
The status of the cross-subsystem path is unknown.
Blockade
The cross-subsystem path is blocked.
Disconnect
Connecting to the external storage system or the external volume is intentionally
stopped using the Disconnect Subsystem command or the Disconnect Volume
command.
Warning
There are cross-subsystem paths whose status is not normal. Check the status of the
cross-subsystem paths.
Checking
The processing of checking the cross-subsystem path status is in progress.
Table 4-8
Pop-up Menu in the Path Operation List (when Subsystem is
clicked)
Pop-up Menu
Description
Allows you to stop the use of the cross-subsystem paths which are connected to the
selected external port of the local storage system.
Allows you to resume using the cross-subsystem paths which are connected to the
selected external port of the local storage system.
