About Universal Volume Manager Operations 2-29
Hitachi Universal Storage Platform V/VM Universal Volume Manager User’s Guide
Note: The emulation type of the prepared internal volume must be
OPEN-V.
3. Set the mapped external volume as the source volume and local storage
system internal volume as the target volume.
4. Migrate the existing data in the mapped external volume to the local
storage system internal volume manually using Volume Migration.
Mapping
Local Storage System External Storage System
Source
Volume
Target
Volume
Migrating data in the mapped external volume (source
volume) to the internal volume (target volume) manually
using Volume Migration.
: Internal volume
: Internal volume where the external volume is mapped
: External volume
Legend
: Data migration direction
Figure 2-12 Example of the Volume Migration Operation
