Using the Universal Volume Manager GUI 4-11
Hitachi Universal Storage Platform V/VM Universal Volume Manager User’s Guide
The Preview dialog box consists of:
• Preview Area
The items set in the list of the Universal Volume Manager windows are
displayed. The contents displayed in the preset area differ depending on
the items set in the list of the Universal Volume Manager windows. The
contents displayed in the preset area are displayed in blue italics in the
list of the Universal Volume Manager windows.
• Operation Information Area
The operation information on the settings displayed in the Preview dialog
box is displayed in the operation information area. Following information is
displayed:
– Operation: name of the setting operation.
– Total Number of Objects in Preview: the number of settings
displayed in the Preview dialog box.
• Close button
The Preview dialog box closes, and returns to the Universal Volume
Manager windows.
• Pop-up menu
Right-click a row in the Preview dialog box to perform the following
operations from the pop-up menu.
– Error Message: Displays the error message of the selected setting.
– Delete: Cancels the settings selected in the Preview dialog box.
