A-6 Connecting External Storage Systems
Hitachi Universal Storage Platform V/VM Universal Volume Manager User’s Guide
Window Names Parameters Parameter Settings
LIP Reset Mode You can either specify this parameter or
omit specifying this parameter.
RS232C Error Information
Outflow Mode You can either specify this parameter or
omit specifying this parameter. Controller Option
Write and verify mode Set this parameter to ON.
Host Connection
Mode Host Connection Mode 1 Set this parameter to Standard Mode.
Host Connection Mode 2 Specify HISUP Mode.
Note: Do not specify any other parameters.
Note: When you use the Thunder 9500V storage system as an external
storage system, the following versions are recommended. If you use a 9500V
storage system whose version is earlier than the following versions, the
information about the SATA drive may not be displayed correctly.
• For Thunder 9530V, Thunder 9520V, Thunder 9570V: version 0658 or
later.
• For Thunder 9580V, Thunder 9585V: version 1658 or later.
Relationship between Serial Number and 9500V Model
When the external storage system is Thunder 9500V storage system, you can
identify the storage system model from the serial number displayed in the
Serial Number column in the Volume Operation window.
The following table describes the relationship between the serial number
displayed in the Serial Number column and the storage system model.
Table A-6 Relationship between Serial Number and 9500V Model
Displayed Serial Number Model
D600XXXX 9570V, 9520V
D60JXXXX 9530V
D60HXXXX 9580V, 9585V
Note: In serial numbers, "X" is an arbitrary number or character.
Relationship between WWN of Port and Controller(9500V)
When the external storage system is Thunder 9500V storage system, you can
identify the controller (controller 0 or controller 1) from the WWN of the port.
