4. Troubleshooting (PROFIBUS DP)
4.2.2 Problems and Countermeasures
Master Unit LED
BF ST
Error Description [Reference]
Light
OFF Green
Light
Blinking Normal
communication - Normal condition
Light
OFF Green
Light ON Ready for
communication - Normal condition
Light
OFF Red
Light
Blinking Communication
error
[Refer to the section 4.2.2.1 Master
Communication Error.]
- Slave disconnected from the network
(Remote I/O communication error)
- Slave not added to the network (Scan list
collation error)
- Nonstandard wiring
- No or too many terminating resistors
- Noise intrusion
Light
OFF Red
Light ON Data link layer
error [Refer to the section 4.2.2.2 Master: Data
Link Layer Error.]
- Nonstandard wiring
- Noise intrusion
Light
OFF Light
OFF Uninitialized
network [Refer to the section 4.2.2.3 Master:
Uninitialized Network.]
- Master unit power error
- Master unit configuration error
Red
Light ON No
Matter Physical error [Refer to the section 4.2.2.4 Master:
Configuration Error.]
- Nonstandard wiring
- Signal wire connection failure
- Signal wire short circuit
