Page 46

*1 Target cameras: SRG-360SHE/280SHE, SRG-300SE/301SE/201SE, SRG-300H/301H, SRG-120DH/121DH/120DS/120DU/HD1,

SRG-X400/201M2, SRG-X120/HD1M2

*2 When the WIDE D(VIEW-DR) function exists in EXPOSURE >MODE >FULL AUTO in the camera menu and it is set to a setting

other than OFF, FULL AUTO mode cannot be set to OFF using the AE button. To switch between AUTO and manual using the AE
button, set WIDE D to OFF.

*3 Enabled when Exposure Mode is set to FULL AUTO or BACK LIGHT in the camera menu.
*4 Setting is enabled in the camera menu.
*5 Except for SRG-X400/201M2 and SRG-X120/HD1M2, the APERTURE setting of the PICTURE menu on the camera is applied.
*6 GAIN Pri cannot be selected.
*7 Setting changes with the frame rate (50 Hz/59.94 Hz). Set CONFIG >RM SETUP >CAMERA FREQ in the RM menu to the frame

rate setting of the camera.

*8 Target cameras: BRC-X1000, BRC-H800, and BRC-H780 with firmware version 2.0 or later
*9 Target cameras: BRC-X1000 and BRC-H800 with firmware version 2.0 or later
*10 On the BRC-X400/X401, GAIN Pri cannot be selected.
*11 Target cameras: SRG-X400/201M2
*12 Target cameras: BRC-X400/X401

FUNCTION
menu of menu
control block

ASSIGN 4 to
ASSIGN 6 buttons

DETAIL LEVEL
display

–

Yes

Adjustment using
VALUE knob after
DETAIL LEVEL is
displayed

On the BRC-H900, enabled if DETAIL
is set to ON in the camera menu.

KNEE POINT
display

–

Yes

–

Adjustment using
VALUE knob after
KNEE POINT is
displayed

Enabled when KNEE is set to ON in
the camera menu, and KNEE MODE is
set to MANUAL.

AE level display

Enabled when the AE button is lit, or if
the AE button is not lit and CONFIG
>RM SETUP >AE CONFIG is not set
to MANUAL in the RM menu.

Yes

Adjustment using
VALUE knob after
AE level is displayed

Enabled when OPERATION
>EXPOSURE >EX-COMP is set to
ON in the RM menu.

ND1 to ND 4 ND
filter settings

–

Yes

–

PP1 to PP6 picture
profile settings

–

Yes

*12

–

IRIS button
(lit blue when
enabled)

IRIS setting display

Enabled when the AE button is not lit.

Yes

Adjustment using
VALUE knob after
IRIS setting is
displayed

Enabled when the AE button is not lit,
and CONFIG >RM SETUP >AE
CONFIG is set to MANUAL or IRIS
Pri in the camera menu.

GAIN button
(lit blue when
enabled)

GAIN setting display Enabled when the AE button is not lit.

Yes

*10

Yes

Adjustment using
VALUE knob after
GAIN setting is
displayed

Enabled when the AE button is not lit,
and CONFIG >RM SETUP >AE
CONFIG is set to MANUAL or GAIN
Pri in the camera menu.

SHUTTER button
(lit blue when
enabled)

Shutter speed display Enabled when the AE button is not lit.

Yes

Adjustment using
VALUE knob after
shutter speed is
displayed

Enabled when the AE button is not lit,
and CONFIG >RM SETUP >AE
CONFIG is set to MANUAL or
SHUTTER Pri in the camera menu.

Yes: Supported

–: Not supported

Control block

Button/knob

Function

Conditions

BRC-X1000/

H800/H780/

X400/X401

BRC-

H900

SRG

series
