Mdr-ds5100, Service manual, Digital surround headphone system

– 1 –
SERVICE MANUAL
US Model
Canadian Model
AEP Model
UK Model
E Model
MDR-DS5100
COMPONENT MODEL NAME FOR MDR-DS5100
DIGITAL SURROUND
HEADPHONE SYSTEM
DIGITAL SURROUND PROCESSOR
DP-IF5100
CORDLESS STEREO HEADPHONES
MDR-IF5000
•
MDR-DS5100 is composed of the following models.
As for the service manual it is issued for each component
model, then, please refer to it.
DP-IF5100
MDR-IF5000
SPECIFICATIONS
Digital surround processor (DP-IF5100)
Decoder functions
Dolby Digital 5.1ch
and 2ch
Dolby Pro Logic
DTS
Virtual sound function
OFF
Virtual front
Virtual surround
Modulation System
Frequency modulation
Carrier wave frequency Right channel 2.8 MHz
Left channel 2.3 MHz
Transmission distance
Approx. 10 m to the front
Transmission range
20 – 20,000 Hz
Distortion rate
1% or less (1 kHz)
Audio inputs
Optical input
(rectangular-type)
×
1
Analog input (pin jack
left/right)
×
1
Power requirements
DC 9 V (from the
supplied AC power
adapter)
Dimensions (w/h/d)
Approx. 85
Ч
190
Ч
180
mm (3 3/8
Ч
7 1/2
Ч
7 1/8
inch)
Mass
Approx. 1.0 kg
(1000 g) (2 lb 30 oz)
•
Manufactured under license from Dolby Laboratories Licensing
Corporation.
DOLBY, the double-D symbol
;
, “PRO LOGIC”,
“Dolby Digital (AC-3)”, and “VIRTUAL DOLBY DIGITAL” are
trademarks of Dolby Laboratories Licensing Corporation.
Cordless stereo headphones
(MDR-IF5000)
Playback frequency range
12 – 24,000 Hz
Power requirements
Rechargeable Ni-Cd
batteries (supplied) or
R6 (size AA) batteries
(dry-cell or
rechargeable, sold
separately)
Mass
Approx. 280 g (10 oz)
(including the
supplied rechargeable
Ni-Cd batteries)
– Continued on next page –
Ver 1.1 2000. 02
