98
Menu List
VIDEO OUTPUT
Menu item Value (bold text: default value) Explanation
VIDEO OUT 1–3 Adjusts the video that is output from the VIDEO OUT 1–3 connectors.
OUTPUT STATUS —
Shows the format and an HDCP signal presence. If there is no connection, “NOT CONNECTED”
is shown.
COLOR SPACE
YPbPr (4:4:4) , YPbPr (4:2:2), RGB
(0–255), RGB (16–235)
Specifies the color space.
DVI-D/HDMI SIGNAL HDMI , DVI-D Specifies the type of output signal.
EXTERNAL REC
CONTROL
OFF, ON
Turns the External Rec control on/off. When this is “ON”, REC START/STOP commands can be
sent to a recorder that supports REC control functionality.
* To use the external REC control function, you must assign the video recording start/stop functions to a
USER button on the dashboard.
BRIGHTNESS -64– 0 –63 Adjusts the brightness.
CONTRAST -64– 0 –63 Adjusts the contrast.
SATURATION -64– 0 –63 Adjusts the saturation.
RED -64– 0 –63 Adjusts the red level.
GREEN -64– 0 –63 Adjusts the green level.
BLUE -64– 0 –63 Adjusts the blue level.
USB OUT
Adjusts the video that is output from the USB STREAM connector.
* You can edit the USB output video format and compression method from the livestreaming app or other app used at the output destination.
OUTPUT STATUS —
Indicates whether the connection uses USB 2.0 (HIGH SPEED) or USB 3.0 (SUPER SPEED).
If not connected to a computer, this indicates “NOT CONNECTED”.
* When “HDCP” in the SYSTEM menu is “ON”, “HDCP MASKED” is displayed, and video/audio is not
outputted from the USB STREAM connector.
OUTPUT FORMAT
Sets the output destination formats that can be selected from the livestreaming app.
YUY2 & MJPEG YUY2 and Motion JPEG are selectable.
YUY2 Only YUY2 is selectable.
CONNECTION RESET EXEC
Reconnects the computer and the VR-6HD when the video is garbled or when operation is
otherwise unstable.
FREEZE
Menu item
Value (bold text: default
value)
Explanation
FREEZE OFF , ON Turns the freeze function on/off. When this is “ON”, the input video is temporarily frozen.
TYPE
Specifies the operation mode for freezes.
ALL
Freezes all video that is being input.
SELECT Freezes only the specified input video.
VIDEO 1–6 (*4) DISABLE, ENABLE
For each input, specifies whether the freeze function is enabled (ENABLE) or disabled
(DISABLE).
(*4) This can be set if “TYPE” is “SELECT”.
