125
Menu List
Menu item Value (bold text: default value) Explanation
MATTE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED , BLUE, BLACK
Specifies the matte color.
EDGE TYPE
OFF , BORDER, DROP, SHADOW,
OUTLINE
Specifies the type of edge applied to the superimposed caption or video.
EDGE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Specifies the color of the edge applied to the superimposed caption or video.
EDGE WIDTH 0– 3 –7 Specifies the width of the edge applied to the superimposed caption or video.
(*1) This can be set if “DSK MODE” is “EXTERNAL KEY”.
(*2) This can be set if “DSK MODE” is “SELF KEY”.
(*3) This can be set if “TYPE” is “CHROMA”.
5: STREAM/RECORD
Menu item Value (bold text: default value) Explanation
START/STOP STOP , ON AIR Starts (stops) streaming/recording.
SERVICE 1, 2
Sets which platform is used for livestreaming.
OFF Livestreaming is not used.
CUSTOM Custom settings are used for streaming.
YouTube Live Uses YouTube Live for streaming.
Facebook Live Uses Facebook Live for streaming.
Twitch Uses Twitch for streaming.
Menu item Value (bold text: default value) Explanation
URL
–
Specifies the URL of the streaming server.
STREAM KEY Specifies the stream key.
USE WEB APPLICATION ENTER Uses a Web app to set the streaming server URL and stream key.
TARGET BITRATE Specifies the target bitrate of encoding.
V.BITRATE 1–5, 6 , 7–20Mbps Specifies the target bitrate of video encoding.
A.BITRATE
32, 48, 64, 96, 128 ,
160, 192, 224, 256
Specifies the target bitrate of audio encoding.
VIDEO REC OFF , ON Sets whether to record an MP4 file (ON) or not (OFF).
AUDIO REC OFF , ON Sets whether to record a WAV file (ON) or not (OFF).
STREAM DELAY OFF , 5–60sec Sets the streaming delay time that’s used by the safety delay function.
SAFETY IMAGE ENTER Loads the still image used for safety delay.
FILE NAME Display only Shows the filename used for the safety delay’s still image.
