5.2 Mounting the Inverter and Battery Pack
Additionally required material (not included in the scope of delivery):
☐ Five screws suitable for the support surface (diameter: at least 6 mm)
☐ Five washers suitable for the screws (outer diameter: at least 18 mm)
☐ If applicable, at least five screw anchors suitable for the support surface and the screws
Risk of injury through lifting or dropping the inverter or Battery Pack
The inverter and Battery Pack are heavy (see Section 11 "Technical Data", page 57). There is
risk of injury if the inverter or Battery Pack is lifted incorrectly or dropped during transport or when
attaching to or removing from the wall.
• Hold the inverter by the right-hand and left-
hand recessed grips, and lift and transport it to
the mounting position horizontally.
• Lift and transport the Battery Pack by the
lateral handles.
Risk of injury due to sharp edges on the wall mounting bracket
• Wear personal protective equipment such as safety gloves.
