Position
Designation
D
SMA radio-controlled socket
The SMA radio-controlled socket supports load control in households with Sun-
ny Home Manager. The SMA radio-controlled socket carries out the following
tasks:
• Implementation of Sunny Home Manager control commands
• Measurement of the energy consumption of the connected load
E
Sunny Home Manager
In the Integrated Storage System, the Sunny Home Manager performs the fol-
lowing tasks:
• Creation of a yield forecast for the PV system based on local weather
forecasts
• Creation of an individual load profile
• Control of SMA radio-controlled sockets
• Control of charging and discharging the Battery Pack based on the yield
forecast and the individual load profile
• Dynamic limitation of active power feed-in by the inverter at the grid-
connection point
• Implementation of grid management specifications
• Transmission of data to Sunny Portal
F
Sunny Portal
Internet portal for monitoring and visualization of the PV system and user inter-
face for the configuration of the Sunny Home Manager and the SMA radio-
controlled sockets. Sunny Portal receives the data from the PV system and from
the SMA radio-controlled sockets. The key PV system data can be accessed
and clearly visualized in Sunny Portal at any time. Settings to be made in the
Sunny Home Manager and the SMA radio-controlled sockets via Sunny Portal
are transmitted to the Sunny Home Manager by Sunny Portal. The Sun-
ny Home Manager transmits the settings to the SMA radio-controlled sockets.
G
Internet
H
Router/network switch
I
Utility grid
K
Feed-in and purchased electricity meter
L
SMA Energy Meter
Measuring device which detects electrical measured values at the connection
point and makes them available via Speedwire. The SMA Energy Meter is a
feed-in and purchased electricity meter.
