Supervisor Setup
• The measurement failed.
• This arc measurement may not be repeatable due to short arc length.
• This line measurement may not be repeatable due to short line length.
• This measurement may not be repeatable due to short axis length.
• This construction is not currently supported.
• There are one or more statistical outlier points in this measurement.
• This distance is valid only in the cardinal directions.
• Poor form - No feature was found for these points.
• Warning: result has poor form.
• Insufficient data - this result could only be approximated.
• The position of the material is ambiguous.
• The result is out of range.
• There is no intersection between these features.
• The points probed in Measure Magic do not make a good enough feature of that type.
• Datum Magic could not complete successfully because an invalid feature type was measured.
• Please use the blob probe for this measurement
• Cannot complete programmed move
• You can’t use the crosshair probe while using Measure Magic or Datum Magic.
• The magnification that you are in has not been calibrated.
• The points that are about to be entered into the measurement may be invalid.
• Sorry, but motors are currently turned off.
• A following error has occurred on your X axis.
• NC control off
• A following error has occurred on your Y axis.
• A following error has occurred on your Z axis.
• A following error has occurred on your Q axis.
• A limit switch on the X axis has been hit!
• A limit switch on the Y axis has been hit!
• A limit switch on the Z axis has been hit!
• A limit switch on the Q axis has been hit!
Specifying Error Messages
