HEIDENHAIN TNC 128 495
21
.3 T
e
c
hnical inf
o
rm
ation
Programming aids  Calculator
 Complete list of all current error messages
 Context-sensitive help function for error messages
 Graphic support for the programming of cycles
 Comment blocks in the NC program
Actual position capture  Actual positions can be transferred directly into the NC program
Test run graphics
Display modes  Graphic simulation before program run, even while another program is being run
 Plan view / projection in 3 planes / 3-D view
 Magnification of details
Programming graphics  In the Programming mode, the contour of the NC blocks is drawn on screen while they
are being entered (2-D pencil-trace graphics), even while another program is running
Program Run graphics
Display modes  Graphic simulation of real-time machining in plan view / projection in 3 planes /
3-D view
Machining time  Calculating the machining time in the Test Run mode of operation
 Display of the current machining time in the Program Run modes
Returning to the contour  Mid-program startup in any block in the program, returning the tool to the calculated
nominal position to continue machining
 Program interruption, contour departure and return
Datum tables  Multiple datum tables, for storing workpiece-related datums
Touch probe cycles  Touch probe calibration
 Datum setting, manual
 Cycles for automatic tool measurement
Specifications
Components  Operating panel
 TFT color flat-panel display with soft keys
Program memory  Minimum 2 GB
Input resolution and display
step  Up to 0.1 µm for linear axes
 Up to 0.0001° for rotary axes
Input range  Maximum 999 999 999 mm or 999 999 999°
Block processing time
3-D straight line without radius
compensation  6 ms
Axis feedback control  Position loop resolution: Signal period of the position encoder/1024
 Cycle time of position controller: 3 ms
 Cycle time of speed controller: 200 µs
Range of traverse  Maximum 100 m (3937 inches)
User functions
