HEIDENHAIN TNC 128 415
16.1
0 Pr
ogr
amming examples
6 CYCL DEF 240 CENTERING Cycle definition: CENTERING
Q200=2 ;SET-UP CLEARANCE
Q343=0 ;SELECT DEPTH/DIA.
Q201=-2 ;DEPTH
Q344=-10 ;DIAMETER
Q206=150 ;FEED RATE FOR PLNGN
Q211=0 ;DWELL TIME AT DEPTH
Q203=+0 ;SURFACE COORDINATE
Q204=50 ;2ND SET-UP CLEARANCE
7 CYCL CALL PAT F5000 M13 Call the cycle in connection with the hole pattern
8 Z+100 R0 FMAX Retract the tool, change the tool
9 TOOL CALL 2 Z S5000 Call the drilling tool (radius 2.4)
10 Z+10 R0 F5000 Move tool to clearance height (enter a value for F)
11 CYCL DEF 200 DRILLING Cycle definition: drilling
Q200=2 ;SET-UP CLEARANCE
Q201=–25 ;DEPTH
Q206=150 ;FEED RATE FOR PECKING
Q202=5 ;PLUNGING DEPTH
Q210=0 ;DWELL TIME AT TOP
Q203=+0 ;SURFACE COORDINATE
Q204=50 ;2ND SET-UP CLEARANCE
Q211=0.2 ;DWELL TIME AT DEPTH
12 CYCL CALL PAT F5000 M13 Call the cycle in connection with the hole pattern
13 Z+100 R0 FMAX Retract the tool
14 TOOL CALL 3 Z S200 Call the tapping tool (radius 3)
15 Z+50 R0 FMAX Move tool to clearance height
16 CYCL DEF 206 TAPPING NEW Cycle definition for tapping
Q200=2 ;SET-UP CLEARANCE
Q201=-25 ;DEPTH OF THREAD
Q206=150 ;FEED RATE FOR PECKING
Q211=0 ;DWELL TIME AT DEPTH
Q203=+0 ;SURFACE COORDINATE
Q204=50 ;2ND SET-UP CLEARANCE
17 CYCL CALL PAT F5000 M13 Call the cycle in connection with the hole pattern
18 Z+100 R0 FMAX M2 Retract the tool, end program
19 END PGM 1 MM
