46 First steps with the TNC 128
1
.3 Pr
ogr
amming the first par
t
 Call the menu for special functions
 Display the functions for point machining
 Select the pattern definition
 Select point entry: Enter the coordinates of the 4
points and confirm each with the ENT key. After
entering the fourth point, save the block with the END
key
 Display the menu for defining the cycle call
 Run the drilling cycle on the defined pattern:
 Confirm Feed rate F=? with the ENT key: Move at
rapid traverse (FMAX)
 Miscellaneous function M? Switch on the spindle and
coolant, e.g. M13. Confirm with the END key: The TNC
saves the entered positioning block
 Retract the tool: Press the orange Z axis key in order
to retract in the tool axis, and enter the value for the
position to be approached, e.g. 250. Confirm with the
ENT key
 Confirm Radius comp.: RL/RR/no comp? by pressing
the ENT key: Do not activate the radius compensation
 Confirm Feed rate F=? with the ENT key: Move at
rapid traverse (FMAX)
 Miscellaneous function M? Enter M2 to end the
program and confirm with the END key: The TNC
saves the entered positioning block
